1/4 3 Flute End Mill 1/8" 1/16" 3mm Aluminum Cutting End Mill Cutter Parallel Shank

Place of Origin Jiangsu, China
Brand Name RLD Tools
Model Number HRC555-3mm
Minimum Order Quantity 1
Price 2.6USD
Packaging Details 1pcs piece of end mill in one plastic tube, 10pcs a bundle, then in a carton.
Delivery Time 5-8 work days
Payment Terms T/T/PayPal/Credit Card
Supply Ability 100000pcs/month
Product Details
Product Name HRC55 3mm Flat End Mill For Alu Flute Dia 3mm
Flute Length 9mm Overall Length 50mm
Shank Dia 3mm Flute Number 3
Helix 40° Suitable Finish Milling
Carbide Rod CB WF25 Coating Uncoating
High Light

1/16 aluminum end mill

,

parallel shank end mill

,

1/8 end mill for aluminum

Leave a Message
Product Description

HRC55 CNC 3 Flutes Solid Tungsten Carbide Flat Aluminum Cutting End Mills Cutter 3mm Parallel Shank



Product name RLD HRC55 3 flutes 3mm square end mill for Aluminum
Size  3×9×50×3D×3F
Suitable for  Aluminum, copper, resin, etc.
Feature  Smooth surface finishing without Milling Marks
Flute Number  3
Coating  Uncoated
Helix angle  40 degree
Co 12%
HRA 92.2
TRS Min(N/mm²) 3800
Tolerance Within 0/-0.02mm
Processing machine ANCA/WALTER





                                             Carbide Raw Material Introduction



End mill grade Carbide rod Grain size HRA Application
HRC50 YG10X 0.6μm 91.8

Aluminum, iron, low alloy steel,

general steel under hardness HRC45

HRC55 WF25 0.6μm 92.2 Cast Iron, Alloy Steel, General steel under hardness HRC50
HRC60 GU25UF 0.4μm 92.5 Super Alloy Steel, Stainless Steel, Titanium, Inconel, Hardened Steel under hardness HRC55
HRC65 GU092 0.2μm 93.5 Alloy Steel, Hardened Steel under hardness HRC62





                                                            Coating   Introduction



Coating name Color Thickness Hardness Friction The Max ℃
AlTiN Black 1.5-3 3300 0.4 900
AlTiSiN Copper 1.5-3 3500 0.35 1000
TiAlN Dark Violet 1-3 3000 0.4 800
Blue Nano Blue 2-4 3200 0.45 1000
AlCrN Dark grey 1.5-3 3500 0.3 1250
DLC Black 1-3 1800 0.1 350
Diamond Black 2-12 10000 0.02-0.1 650
Coating can be customized



RLD Square End Mill for Aluminium Standard Size
HRC50
Flute Dia(mm) Overall Length(mm) Cutting Length(mm) Shank Dia(mm) Flutes
1 50 3 4 2/3
2 50 6 4 2/3
3 50 9 4 2/3
4 50 12 4 2/3
4 75 16 4 2/3
4 100 20 4 2/3
6 50 18 6 2/3
6 75 24 6 2/3
6 100 30 6 2/3
8 60 24 8 2/3
8 75 32 8 2/3
8 100 40 8 2/3
10 75 30 10 2/3
10 100 40 10 2/3
12 75 36 12 2/3
14 100 45 14 2/3
16 100 45 16 2/3
18 100 45 18 2/3
20 100 45 20 2/3

1/4 3 Flute End Mill 1/8" 1/16" 3mm Aluminum Cutting End Mill Cutter Parallel Shank 01/4 3 Flute End Mill 1/8" 1/16" 3mm Aluminum Cutting End Mill Cutter Parallel Shank 1

                                       FAQ



1. Are you a manufacturer or trading company?

We are a professional manufacturer of carbide tools which was established in 2011.



2. Which shipping method do you usually use?

We usually send goods by express like DHL, UPS, FedEx, etc.

We also can send the parcels to your shipping agent in China.



3. How about the delivery time?

Around 1-3 working days after receiving the payment for the end mills in stock.
Around 7-10 working days after receiving the payment for the end mills out of stock.

Large quantities will take a longer time to produce.



4. Which payment methods do you accept?

We accept T/T, Trade Assurance Order on Alibaba(credit card), PayPal, etc.



5. Can you produce special carbide tools?

Yes, we can produce customized carbide tools according to your drawings or samples.



6. Can you do OEM?
Yes, we can engrave your logo on the tool's shank and make customized stickers.



7. Do you have any discounts?

Yes, more quantity will enjoy more discount.

Welcome to send inquiry to us.



8. What is the location of your factory?
Our factory is located in Changzhou City, Jiangsu Province, China.
